SOLAR WATER PUMP SYSTEM

SOLAR WATER PUMP SYSTEM

A solar pump uses power derived from sunlight that is converted into electrical power by Solar Photo Voltaic (SPV) modules, which give higher power output in the afternoons and lower power output in the mornings and evenings. E.g. a standard 5 HP pump working on grid power/ diesel engine for, say 2.5 hours a day, may give the same water output in a day as a solar pump of 3 HP working for 8 hours using sunlight. This is an important fact to keep in mind for appropriate solar pump selection and application engineering. The most important parameters to select a solar pump are: how much daily water is needed, at what pump head, and at which location. The location is important because solar energy varies from region to region, and sizing of solar panels depends on the solar energy of a region

Main Features:

• Suitable for 1HP to 7.5HP surface mount and submersible pumps with 3-phase AC asynchronous motors.
• Corrosion resistant, IP55 enclosure for drive suitable for outdoor installation.
• Pump overload, dry run protection

Benefits

• Pumping of water in for irrigation for drinking water supply in off grid areas.
• Farmer can cultivate multiple crops through out the year in off grid areas
• Lower operation expense compared to diesel pumps
• Zero emission of green house gases.
